ARCA-JIC

Get to Know the ARCA-JIC

With its formed-in-place PUR gasket, the ARCA-JIC protects sensitive equipment from water ingress and keeps electrical systems free from dust and dirt, making it the ideal indoor or outdoor enclosure.

Our polycarbonate NEMA 4X enclosures are designed for the harshest locations and offer more than just a plastic box or a hinged plastic electrical enclosure. The ARCA-JIC series is UV- and impact-resistant and has an IK 09 rating, ensuring years of active outdoor service. Rust-free polycarbonate also offers excellent chemical resistance compared to metal and fiberglass boxes.

Fibox non-metallic polycarbonate enclosures are wi-fi friendly and provide an excellent solution for the 5G/6G revolution, eliminating the need for external antennas.

Custom Electrical Enclosures with Opaque or Clear Lids

Our polycarbonate NEMA 4X enclosures with clear lids offer the largest viewing area compared to an inserted sight window. We also provide custom electrical enclosures with opaque or clear lids, which can be customized to your application's specific needs, offering tailored and customized solutions. Your modified enclosure will represent you and your brand with cutouts, printing, labeling, and color painting. We stock all the standard hardware and accessories you might need, and our non-metallic enclosures range in size from 6.0 x 6.0 x 4.0 to 24.0 x 24.0 x 10.0 inches, with various cover options available.

The ARCA-JIC is a watertight NEMA 4X and 6P non-metallic enclosure that consistently outperforms metal and fiberglass boxes and makes an excellent industrial control panel enclosure, or junction box. Use our NEMA-rated cable glands to retain your enclosures’ NEMA 4X status and bypass gasket, glued-in, or bolted-on windows with a clear lid. Fibox is proud to offer the industry’s first and only NEMA 4X JIC enclosure with formed-in-place knockouts which save time and eliminate the need for DIY customization.

To specify an application and receive a quote, contact Fibox customer service.

ARCA-JIC

ARCA-JIC Technical Information

Conformity to standards:

• USA Enclosures for Electrical Equipment
  UL Type 4, 4x, 6, 6P, 12, and 13
• NRTL Listing
  Underwriters Laboratories UL
  cUL Listed under UL 508
  SGS FIMKO CE Conformity
  RoHS directive 2002/95/EC
  GostR - Gost Russian certificate of conformity

Data subject to change without notice.
* Consult separate raw material data for more detailed information.

The Fibox ARCA - JIC Polycarbonate Enclosures are engineered to excel in harsh and demanding environments, offering a robust and reliable solution for protecting your equipment. Here are some of the standout features:

• Dimensions Range: Available in a variety of sizes, from 203 mm x 203 mm x 102 mm to 800 mm x 600 mm x 300 mm, these enclosures can accommodate a wide range of applications.

• Material: Constructed from high-quality polycarbonate, these enclosures provide exceptional impact resistance and durability, ensuring long-term performance.

• Ingress Protection: With an IP66/IP67 rating, the ARCA PC Enclosures are designed to prevent dust and water ingress, making them ideal for the most demanding environments.

• Cover Screws: Made of stainless steel, the cover screws offer excellent corrosion resistance, enhancing the longevity of the enclosures.

• UL Type: These enclosures meet UL Type 4, 4X, 6, 6P, 12, and 13 standards, ensuring they are suitable for a variety of applications.

• Temperature Range: Designed to withstand extreme temperatures, these enclosures operate effectively from -40°C to 140°C (-40°F to 284°F) for short-term use and -40°C to 80°C (-40°F to 175°F) for continuous use.

• Cost-Effective Alternative: Offering similar features and benefits to traditional stainless steel enclosures, the ARCA PC Enclosures provide a more cost-effective solution without compromising on quality.

• Hinged Cover: The hinged cover design allows for easy access to the interior, simplifying the installation and maintenance of equipment.

• Width and Depth: With widths ranging from 203 mm to 800 mm and depths from 102 mm to 300 mm, these enclosures are versatile enough to meet various application needs.

• Continuous Use: Built for continuous use in harsh and demanding environments, these enclosures ensure reliable protection for your equipment.

• Box Design: The robust box design provides a secure and protected environment, making it ideal for applications where equipment needs to be shielded from the elements.

• UL Certification: Meeting stringent UL standards, these enclosures are certified for use in a wide range of applications.

• Short-Term Use: Capable of withstanding temperatures from -40°C to 140°C (-40°F to 284°F) for short-term use, these enclosures are suitable for extreme conditions.

• Features: The ARCA PC Enclosures are packed with features that make them perfect for harsh and demanding environments, including ingress protection, stainless steel cover screws, and a hinged cover.

• ARCA Range: As part of the ARCA range, these enclosures are known for their high quality and durability.

• Celsius and Fahrenheit: The enclosures are designed to operate within a temperature range of -40°C to 140°C (-40°F to 284°F) for short-term use and -40°C to 80°C (-40°F to 175°F) for continuous use.

• Harsh and Demanding Environments: Specifically designed for use in harsh and demanding environments, these enclosures provide reliable protection against extreme temperatures, dust, and water ingress.

• Most Demanding Environments: Engineered to perform in the most demanding environments, these enclosures ensure your equipment remains protected under the toughest conditions.

• Stainless Steel: The use of stainless steel for cover screws enhances corrosion resistance, ensuring the longevity of the enclosures.

• 4X, 6, 6P, & 12: Meeting UL Type 4, 4X, 6, 6P, 12, and 13 standards, these enclosures are versatile and suitable for a wide range of applications.

• 4, 4X, 6, & 6P: Compliant with UL Type 4, 4X, 6, 6P, 12, and 13 standards, these enclosures offer reliable protection for various applications.

By incorporating these features, the Fibox ARCA PC Enclosures stand out as a reliable and cost-effective solution for protecting your equipment in the most challenging environments.
